Sundance Spas 6600-110 Hi-Limit Sensor - Box-End Connectors
Sundance Spas 6600-110 Hi-Limit Sensor - Box-End ConnectorsSundance Spas$59.87
Loading...
Loading...
Loading...
Loading...
Sundance Spas
Use with 8820456 Oring (sold separately, see below in related products.)
Used on these Sundance® Spas:
Used on the following Jacuzzi® Spas models:
Location of Temp Sensor: The Temp Sensors are located in the filter compartment on the side. They are unscrewed from the inside of the tub and the wire is fed through a tube into the equipment compartment. Follow the wire to the PC Board. To feed the new sensor, we usually drain the tub below the hole and pull the old sensor out a couple of feet into the tub, cutting the old sensor head off, we tie on the new sensor (connector end) to the old wire and pull the wire through into the equipment compartment.
Diagnostic and Installation: The connectors on the Temp Sensor are attached to a pc board connector that is located on the PC Board (usually at the top). See these instructions for Diagnostic and Installation: http://www.spaandpoolsource.com/sundancespastemperaturesensordiagnostic.aspx
Please note: The color code on the wires have no significance, you can hook the wires up either way.
These sensors are interchangeable with the 6600-166 except for the end connector which does not connect into the 6600-167 harness. (would have to strip wires back and wire nut together.)
