US Motors SPH30FL1 by Nidec Corp (formerly Emerson Motors) Single Speed 240 Volt with stand, threaded Shaft, Thru Bolt, 48 Frame.
Used on Sundance® Spas and Jacuzzi® Spas Single Speed Pumps
Used on Pumps with part numbers: 6500-341, 6500-263, 6500-763, 6500-269, 6500-769, 6500-266, 6500-766, 6500-349
Cannot be used on the Aqua-Flo used from 1997-1999 part number: 6500-126. Also cannot replace the 2009 or newer motor from Sundance® Spas/Jacuzzi® Spas that is called LX.
Specifications:
- 1 Speed
- 230/240 Volt
- 12.0 Amps (measured at 6 MBHP with Aquaflo/Gecko wet end) 10.0 Amps (measured at 4.2/2.5 HP with Sundance® Spas/Jacuzzi® Spas wet end)
- 48 Frame
- Motor rated at 3 HP, 230 Volts
- Alternate Part Numbers: SPH30FL1, T55MWBNN-1009, T55MWBNN1009, T55CXBLR-968
The difference between the Factory OEM Motor is that ours comes with the original welded bracket on the motor instead of the bracket mount currently used by Sundance® Spas. Our motor replaces the original found in your spa that had the mounting bracket welded to it. Make sure that your motor was a 48 frame, Single Speed used on the above pumps listed.
